X,Y,Z Arbitrary Angle Motorized Rotary Stage:WN303

Short Description:

Send email to us

Product Detail

Product Tags

Model		WN303RA200M-D
Structure Description	Rotation Range	Around the X, Y, Z-axis 360 ° arbitrary angle
	Table Size	φ100
	Worm Gear Ratio	180∶1
	Drive Mechanism	Motorized Rotation Stage
	Travel Guide	Bearing
	Stepper Motor(1.8°)	Z-Axis 200w servo motor, Z,Y-Axis 100w servo motor
	Base Material	Aluminum Alloy
	Surface Treatment	Black-Anodized
	Center Load Capacity	10kg
	Weight	23kg
Accuracy	Resolution	0.72″
	Speed	35°/sec
	Repeatability	0.005°=18″
	Backlash	0.005°=18″
	Conductive slip ring: 2

Features:

.Standard servo motors and RS232 interface.

.Compatible with the Models WNMPC08 Series of Motion Controller

.Rotating shafts using multi-channel technology of precision processing, with high precision, large capacity and long life

. Using precision worm structure , exercise comfortable, forward and reverse rotation can be arbitrary and minimal backlash
