Rotary Stage:WNKS421-60

Short Description:


Product Detail

Product Tags



Model
WNKS421-60
Structure
Description
Angle Range
360°
Stage Diameter
φ60mm
Transmission Ratio
1:2
Actuator Type
Worm Gear
Travel Guide
Bearing
Stepper Motor(1.8°)
SST28D2121
Base Material
Aluminum Alloy
Surface Treatment
Black-anodized
Load Capacity
10kg
Weight
1kg
Accuracy
Description
Resolution
0.02°(non MicroStep)
0.001°(20MicroStep Driver)
Speed
25°/sec
Surface vibration
30μm
Accessories
Description
            Servo Motor(-D)

Features:
.Standard stepper motors and RS232 interface.
.Compatible with the Models WNMPC08 Series of Motion Controller
