Rotary Stage:WNKS421-100

Short Description:


Product Detail

Product Tags



Model
WNKS421-100
Structure
Description
Angle Range
360°
Stage Diameter
104mm
Transmission Ratio
4:1
Actuator Type
Belt
Travel Guide
Bearing
Stepper Motor(1.8°)
SST42D2121
Base Material
Aluminum Alloy
Surface Treatment
Black-anodized
Load Capacity
5-10KG
Weight
2.1KG
Accuracy
Description
Resolution
0.1°
Speed
360°/sec
Backlash
Lost Motion
<0.1°



















Features:
.Standard stepper motors and RS232 interface.
.Compatible with the Models WNMPC08 Series of Motion Controller
