Precise Prism Tables:WN03PT

Model

WN03PT

Key Features

l          Orthogonal, coplanar angular adjustment

l          Uncoupled tilt adjustments with sensitivity to 5′

l          Standard or lockable adjustment screws or differential micrometer

Stage Size

60mm×60mm

Function

θx , θy Tip Adjustment

Diver Mode

Differential Micrometers

Adjustment Range

Tip and Tilt ±5°

Sensitivity

5′

Load Capacity

0.5kg

Weight

0.12kg

Material

  Duralumin

Surface Treatment

Black-Anodized
