Motorized Lab Jack:WNKS332-20 Featured Image

Motorized Lab Jack:WNKS332-20

Short Description:

Send email to us

Product Detail

Product Tags

Model	WNKS332-20
Table Size	150×150
.Actuator Type	Cross Roller Guide
Travel Guide	Grinding Screw Assembly
Travel Range	20mm
Stepper Motor(1.8°)	SST57D2121
Load Capacity	40Kg
Min. Adjustment	1.875μ（non MicroStep）
Max Speed	3mm/sec
Repeatability	3μ
Backlash	2μ
Lost Motion	1μ
Weight	4.7kg
Base Material	Aluminum Alloy
Surface Treatment	Black-anodized

Features:

.Standard stepper motors and RS232 interface.

.Compatible with the Models WNMPC08 Series of Motion Controller

.Accept the restructuring and customized products

.Lab jack using cross roller guides to ensure smooth motion, carrying large and long life
