Model | WN261TA15H | WN261TA30H | WN261TA50H | WN261TA75H | Structure
Description | Travel Range | 15 mm | 30 mm | 50 mm | 75 mm | Table Size | 65×65mm | 90×90 mm | 90×110mm | 90×135mm | Screw Spec. | Grinding Screw
(Travel Range 0.5 mm) | Grinding Screw (Travel Range 1 mm) | Travel Guide | High Precise V-groove & Crossed Rollers | Stepper Motor(1.8°) | STP-42D3016 | Base Material | Aluminum Alloy | Surface Treatment | Black-anodized | Load Capacity | 10kg | 15kg | 20 kg | Weight | 1.2kg | 1.25kg | 1.4kg | 1.7kg | Accuracy Description | Resolution | 2.5μ/Pulse (non MicroStep)
0.125μ/Pulse (20 MicroStep Driver in use) | 5μ/Pulse (non MicroStep) 0.25μ/Pulse (20 MicroStep Driver in use) | Maximum Speed | 5mm /sec | 10mm /sec | Repeatability | 3μ | 5μ | Positional Accuracy | 10μ | Straightness | 5µ | 8µ | 12µ | Driving Parallelism | 10µ | 15µ | Pitching | 25″ | Yawing | 20″ | Backlash | 2µ | Lost Motion | 2µ | Accessories
Description | Limit Switch & Origin Sensor | Grating (G) | Servo Motor (D) | Key Features | - Non-contact direct-drive system ensures ultraprecision motion with high dynamics and reliability
- Extra-large, high-efficiency linear motor minimizes heat generation
- Ironless moving coil has no cogging for ultra smooth velocity control
- Ultra-quiet anti-creep crossed roller bearings assure ripple-free motion without cage migration
- High precision glass scale encoder provides accurate position feedback with 50 nm repeatability
- Sub-nm resolution with low interpolation error for outstanding speed stability and motion sensitivity
- No moving cables inside the stage, reduced particle generation and improved reliability
|
|
 |
| |
