Mini Motorized Linear Stages:WN267TA20H

Short Description:


Product Detail

Product Tags



Travel Range
20mm
Resolution
0.125μm
Repeatability
<1μm
Straightness
<2μm
Parallelism
<5μm
Pitching(θy)
10″(50μrad)
Yawing(θz)
10″(50μrad)
Maximum Speed
5mm/sec
Load Capacity
10kg
Weight
1.5kg
Features:
Ultra-precision motorized stage using high subdivision stepper motor driver, high resolution.
Imported high-precision ultra-thin linear slide to ensure the high accuracy , compact, is the first choice for fine adjustment
