High Precision:WN268TA(50-150)M

Short Description:

Product Detail

Product Tags

Model		WN268TA50M	WN268TA100M	WN268TA150M
Structure Description	Travel Range	50 mm	100 mm	150 mm
	Table Size	120×125mm	120×165mm	115×115mm
	Bearing Construction	High Precision Ball Screw（4mm of leading）
	Travel Guide	High Precision Cross Roller Guide
	Stepper Motor(1.8°)	Steeper Motor
	Base Material	Hard Aluminum Alloy
	Load Capacity	40 kg
	Weight	3kg	5kg	8kg
Accuracy Description	Design Resolution	20µ（Non-MS Drive） 1µ（20 MS Drive）
	Max. Velocity	20mm/sec
	Repeatability	1µ
	Straightness	8µ		10µ
	Parallelism	15µ		20µ
Accessories Description	Grating Scale(-G)

Features:

.High precise ball screw and cross roller guide provides high-performance, high-accuracy and high-load,suitable for industrial processing, laboratory or need high load speed, long-term continuous operation place.

.Applies to use in single axis or assemble into multi-axis stages,decreased the height when assemble to X,Y
