High Precision Rotary Stage:WN260RA40H

Short Description:


Product Detail

Product Tags



Model
WN260RA40H
Structure
Description
Angle Range
360°
Stage Diameter
Φ39mm
Transmission Ratio
120:1
Actuator Type
Worm Gear
Travel Guide
Bearing
Stepper Motor(1.8°)
11HD1008-01
Base Material
Aluminum Alloy
Surface Treatment
Black-anodized
Load Capacity
2Kg
Weight
0.3Kg
Accuracy
Description
Resolution
0.015°=54″（non MicroStep）
0.00075°=2.7″（20MicroStep Driver）
Speed
15°/sec
Repeatability
0.0067°=24″
Backlash
0.0067°=24″

Features:
. 39 mm diameter through-hole for convenient cable routing
.Standard stepper motors and RS232 interface.
.Compatible with the Models WNMPC08 Series of Motion Controller
.Can increase the limit function,  initial zero, change to servo motor, rotary encoder, accept the restructuring and customized products
